0.6/1kV Aerial Bundle Cable IEC 60502-1

Aerial Electrical Power Transmission Line Used AAC conductor Insulated Cable

Application

Aerial bundle cable (ABC) low voltage cable for overhead power distribution offering higher level of safety and reliability and lower power losses than bare conductors.

Share This Page

ABC Cable / Aerial Bundled Cable

Airport Lighting Cable

Bare overhead conductor

Concentric Service Cable

Control Cable

Installation / Building Cable

Low Voltage Cable

Medium Voltage Cable

Solar Cable

Standards

IEC60502-1

Construction

Phase conductors: AAC

Insulation: XLPE, UV-resistant.

Neutral-supported: AAC

Core identification: Ribs or numbers or colors stripe.

Characteristics

Voltage rating: 0.6/1kV
Test voltage: 3.5kV, 5min no breakdown.
Operating temperature: -40°C to +90°C
Minimum laying/installation temperature: -20°C
Minimum bending radius: 12x OD (overall diameter)

Specifications

Number of Cores x Nominal Cross Section No.×mm²	Approx. Overall Diameter mm	Approx. Weight Kg/Km	Max. DC Conductor resistance at 20℃ Ω/Km	Minimum Breaking Load kN	Current Rating A
3×16+1×25 RM	19	290	1,91	4,0	107
3×25+1×25 RM	23.2	400	1,200	5,5	132
3×35+1×25 RM	25.6	500	0,868	8,0	165
3×50+1×35 RM	30	680	0,641	10,7	205
3×70+1×50 RM	34.9	920	0,443	13,7	240
3×95+1×70 RM	40.6	1270	0,320	18,6	290
3×120+1×70 RM	44.1	1510	0,253	23,2	334
3×150+1×95 RM	49.2	1870	0,206	28,7	389
3×185+1×120 RM	54.9	2340	0,164	37,2	467
3×25+1×25+1×16 RM	23.2	470	1,200	2,5	72
3×35+1×25+1×16 RM	25.6	560	0,868	4,0	107
3×50+1×35+1×16 RM	30	740	0,641	5,5	132
3×70+1×50+1×16 RM	34.9	980	0,443	8,0	165
3×95+1×70+1×16 RM	40.6	1330	0,320	10,7	205
3×120+1×70+1×16 RM	44.1	1580	0,253	13,7	240
3×150+1×95+1×16 RM	49.2	1940	0,206	23,2	334
3×185+1×120+1×16 RM	54.9	2410	0,164	2,5	72
